Noise Diodes
NoiseWave’s noise diodes offer a symmetrical white Gaussian noise voltage distribution while maintaining a flat power spectral density versus frequency response. Applications for these diodes include built in test equipment, dithering for increased dynamic range of A/D converters, and as an economical source of broadband power.
Diodes are available in a variety of packages including an industry standard SOD-323 package, which allows it to be economically produced.
Specifications:
Operating temperature:
-55 to +125 deg C
Storage Temperature:
-65 to +150 °C
Output:
White Gaussian noise
Model Number
Frequency
V
I
RL
uV/√Hz
PACKAGE
NW101
0.1Hz - 100KHz
7-10
30 - 60uA
2200
3.0
D0-35
NW102
0.1Hz - 500KHz
7-10
30 - 60uA
2200
3.0
D0-35
NW103
0.1Hz - 1MHz
7-10
30 - 60uA
2200
3.0
D0-35
NW104
0.1Hz - 3MHz
7-10
30 - 60uA
2200
3.0
D0-35
NW201
0.1Hz - 10MHz
7-10
0.2 -0.5mA
2200
0.1
D0-35
NW202
0.1Hz - 25MHz
7-10
0.2 -0.5mA
2200
0.1
D0-35
NW203
0.1Hz - 100MHz
7-10
0.2 -0.5mA
50
0.05
D0-35
ENR
NW301
10Hz - 3GHz
8-12
5mA
50
30 - 35
SOD-323
NW302
10Hz - 6GHz
7-11
6mA
50
30 - 35
SOD-323, CH2
NW303
10Hz-8GHz
8-12
8mA
50
30 - 35
BL, CH2
NW305
10MHz-11GHz
8-12
10mA
50
30 - 35
BL, CH2
NW401
10MHz-18GHz
8-12
10mA
50
28-33
P50, C, CH2
NW402
10MHz-40GHz
8-12
15mA
50
25-30
P50, C
Download Spec Sheet
